6000 Series Pure Aluminum Plate/Coil/Bar/Pipe

Al metal alloy: 1000, 2000, 3000, 4000, 5000, 6000, 7000, 8000 series etc

Alu temper: O - H112, T3 - T8, T351 - T851 etc

Width: 200mm - 2650mm

Thickness: 0.2mm - 8mm

Technology:  hot rolled ( DC ), cold rolling ( CC ), cast

Standard: ASTM B209, GB/T 3880, EN AW etc

6063 alloy aluminum coil belongs to 6000 series alloy aluminum coil. 6063 aluminum coil is an aluminum alloy with magnesium and silicon as the alloying elements. ZHONGZHILIAN delivers customized 6063 aluminum coil, plate and coil with excellent properties like weldability, corrosion resistance and machinability. The mechanical properties of 6063 depend greatly on the temper, or heat treatment, of the material. Commonly used tempers are O, H4, H6, H651, F and etc.

The All material from ZHONGZHILIAN  is fully certified to ASTM, EN, and JIS. Both MSDS and ROHS are available according to your specific

Checmical Composition Of 6063 Aluminum Coils

Si ( Silicon ): 0.2 – 0.6

Cu ( Copper ): ≤ 0.1

Mg ( Magnesium ): 0.45 – 0.9

Zn ( Zinc ): ≤ 0.1

Mn ( Manganese ): ≤ 0.1

Cr ( Chromium ): ≤ 0.1

Fe ( Iron ): ≤ 0.35

Ti ( Titanium ):≤ 0.1

Others total: ≤ 0.2

Al ( Aluminum ): remainder

6063 Aluminum coil has generally good mechanical properties and is heat treatable and highly wieldable. The material can be re-heat-treated to restore a higher temper for the whole piece. However it has half the strength of aluminum 6061 alloys. It is typically produced with very smooth surfaces fit for anodizing and often used to make auto parts, architectural fabrication, window and door frames, aluminium furniture, electronic components as well as various consumer durable products.

ZHONGZHILIAN Alu offers 6063 aluminum coil, get a quote online.

Product Parameter
