Chemical Composition (%) of 410 Stainless Steel Pipe
C |
Mn |
Si |
P |
S |
Cr |
Ni |
0.15 |
1.0 |
1.0 |
0.04 |
0.03 |
11.5-13.5 |
0.5 |
Mechanical Properties of 410 Stainless Steel Pipe
Tensile Strength MPa (min) |
Yield Strength 0.2% MPa(min) |
Elongation % |
Hardness (Brinell) MAX |
Hardness (Rockwell B) MAX |
450 |
205 |
20 |
217 |
96 |
Physical Properties of 410 Stainless Steel Pipe
Density
lbm/in3 |
Thermal Conductivity
(BTU/h ft. °F) |
Electrical
Resistivity
(in x 10-6) |
Modulus of
Elasticity
(psi x 106 |
Coefficient of
Thermal Expansion
(in/in)/
°F x 10-6 |
Specific Heat
(BTU/lb/
°F) |
Melting
Range
(°F) |
at 68°F: 0.276 |
14.4 at 212°F |
56 at 68°F |
29 |
5.90 at 68 – 392°F |
0.11 at 68°F to 212°F |
2700 to 2790 |
Alloy 410 is the basic, general purpose martensitic stainless steel that is used for highly stressed parts and provides good corrosion resistance plus high strength and hardness. Alloy 410 contains a minimum of 11.5% chromium which is just sufficient enough to demonstrate corrosion resistance properties in mild atmospheres, steam, and many mild chemical environments.
It is a general purpose grade that is often supplied in the hardened but still machineable condition for applications where high strength and moderate heat and corrosion resistance are required. Alloy 410 displays maximum corrosion resistance when it’s been hardened, tempered, and then polished.
If you are interested in other Stainless Steel Pipe, please click 302, 303, 304, 304L, 304H, 309, 309S, 310, 310S, 310H, 316, 316L, 317/317L, 317LMN, 321, 321H, 330, 347, 347H, 904L, 403, 405, 409, 410, 410S, 410/HT, 416, 416HT, 420, 422, 430, 440C, Duplex 2205, Duplex 2304, Duplex 2507.
